Inflatable Dock Shelters are used for door openings in vehicle loading and unloading areas to ensure a sealed environment during the loading and unloading process. After the vehicle stops, turn on the electric switch, and the inflatable dock shelter blower begins to inflate, completely closing the gap between the three sides of the carriage and the opening. The surface material of the dock shelter is soft and does not damage the vehicle's surface. During operation, the blower needs to continue working to ensure the pressure of the airbag and a certain degree of wind resistance. After completing the process, turn off the blower switch. The airbag will deflate through the exhaust hole, and the airbag will be automatically retracted through the built-in balance weight.
Inflate the airbag to wrap around the three sides of the car, providing an excellent sealing effect.
Large adjustable space
Large adjustable space to meet the sealing needs of different parked vehicles.
Multiple security measures
Safety warning tape: Standardize the parking range of vehicles. Reverse rail (optional accessory): Standardize vehicle parking to avoid accidental collisions during parking. Red and green indicator lights (optional accessory): Avoid accidental collisions during parking.
Parts Design Highlights
01
High quality polyethylene fiber material, with high wear resistance and flexibility, can meet a service life of not less than 30000 times.
02
Special protective curtains for airbags prevent the airbag from being damaged when the vehicle is parked, greatly extending its service life.
Process Highlights
Fully automatic door curtain production equipment, cutting speed of 1m/s, size error not exceeding 1mm;
The continuous, fully automatic production line from Bayer Hennecke in Germany, with super strong insulation, was imported.
Inflatable dock shelter have the best sealing performance and cover most car models. Choosing the appropriate size according to the actual vehicle model is necessary, which can meet the sealing requirements of all vehicle models.
Inflatable dock shelters have the best sealing performance and cover most car models. However, it is necessary to avoid frequent collisions with vehicles during use. Multiple protective measures can be taken: 1) Using reverse rails to limit the range of vehicle parking can ensure accurate stopping of the vehicle at once and prevent it from hitting the side insulation board; 2) Professional personnel are required to guide vehicles to their designated parking locations to avoid collisions caused by blind spots in the driver's line of sight.
